MoTeC M1 Firmware: JRR GM LS 58x

JRR GM LS 58x firmware license for MoTeC M1 ECU

• If you are a MoTeC dealer or already own an M1 ECU, you can purchase just the firmware license - no ECU purchase required

• This firmware package will work with any GM LS V8 engine with the OE 58x crank trigger pattern and 4 tooth sync pattern


• This firmware features full CAN integration for C6 Corvette (2005-2013), Gen 5 Camaro (2010-2015) and Gen 2 CTS-V (2009-2015)

• A paddle shift gearbox control version of this firmware is also available, which is based on JRR Universal Motorsports Paddle Shift/MoTeC GPR-P, for running air shifted sequential gearboxes.

• When ordering this firmware combined with a new M1 ECU, enter 0 for the serial number.

Base Calibrations:

• Standard:
• 2014 Camaro LS7 Start Up Rev 5, M150 (rev 01.00.0004)
• 2009 Corvette Z06 LS7 Start Up Rev 5, M150 (rev 01.00.0004)
• 2011 CTS-V 6L90 Start Up Rev 5, M150 (rev 01.00.0004)

This firmware is based upon JRR Universal Motorsport/MoTeC GPR and includes the following additional features:

• Integrates fully with OE CAN bus - maintains proper vehicle operation and dash functionality

• Advanced boost control strategy with flexible table setup options and support for electronic wastegate, dual boost solenoids and comprehensive CO2 control

• Two stage nitrous control - various parameters supplied to control nitrous. Includes nitrous bottle heater relay control based on nitrous pressure

• Supports flex fuel and dual fuel configurations

• Supports standard gear lever shifted sequential gearboxes, with closed loop gear cut/blip control using shifter load cell and barrel position sensor.
• Water injection control - with failsafe for boost/timing/fuel based on pressure sensor feedback

• Direct control of most electronically shifted 4 speed automatics with lock-up torque converter control

• Features calculated engine speed based traction control (from MoTeC GPR), as well as wheel speed differential traction control (similar to the M800) for automatic transmissions or any other setup with slip between the engine and the drive wheels.
• Integrated transbrake bump control with programmable creep feature
• Cruise control, using OE controls and display
• Advanced CAN transmit and receive, which features both standard M1 features as well as a new custom CAN setup allowing user defined flexibility to send and receive messages to other devices.
• Comprehensive engine protection strategies including high temps, low fuel pressure, low oil pressure, injector duty cycle, and many more

• Air bypass anti-lag control - for increased ALS performance (when used with appropriate engine hardware)

• Specifically supports MoTeC LTC and AEMnet lambda devices via CAN, as well as most other CAN and analog widebands using generic configurations.

• Supports direct input from Obsidian INS and Racegrade IMU

• Supports direct input from a MoTeC/Racegrade CAN keypad

• The lower price (compared to GPR) is due to this firmware being locked to the OE engine (unless otherwise noted). Locking is done by hard coding the crank and cam trigger pattern, cylinder number and firing order in the firmware. To change to a different engine or non stock trigger pattern requires purchasing a different firmware license. Multiple firmware licenses can be installed on a single ECU.

• Like anything, the MoTeC M1 requires knowledge and experience to gain the best results. While we are happy to answer technical questions, purchase of this M1 firmware does not come with unlimited tuning support. We can quote tuning for your particular setup, refer you to someone in your area, or if you prefer to do it yourself (and lack the experience) then we can also quote training.

• This firmware is for closed course competition vehicles only. It does not meet federal emissions requirements.
