MoTeC M1 Firmware: MoTeC GP Marine

MoTeC GP Marine firmware license for MoTeC M1 ECU

MoTeC's M1 GP Marine Package is a versatile and adaptable platform for the operation of port-injected marine engines. These can be inboard or outboard. This single product can be configured over a huge range of complexities, from controlling a simple engine to a multi-throttle, quad cam boosted engine with two injectors per cylinder and many other features. Configurable engine synchronisation modes accommodate most modern engine triggering systems.

Included are numerous ancillary features, such as boost limit, drive trim control, trim tab control, gearbox control, knock control and launch control. It also caters for many systems found on marine vessels that may be useful in a racing context.

This firmware is available across MoTeC's range of M1 port injection ECUs (M130, M150, M170 and M190). The product provides pre-defined CAN messaging for full integration with other MoTeC products like Display Loggers, Video, Power Distribution Modules, Expanders, Shift Lights and more.

When ordering this firmware combined with a new M1 ECU, enter 0 for the serial number.

Ensure your serial number is accurate. This license is not refundable and cannot be moved to a different serial number after ordering.

Marine Specific Features

• Drive Trim Control

• Starboard and Port Trim Tab Control

• Support of Mercury OE Systems:

  • Dash Warnings supported and enabled through M1 Warning Module

  • Mercury OE DTS Systems via CAN: Throttle Lever, Crank Request, Gear Position Request, Drive Trim Up and Down Request

  • Multi Engine Support - Up to 6

  • Multi Engine Synchronisation

• Jet Powered Boat features including: Intake, Trim, Nozzle and Stator Pressure sensors and Reverse Bucket actuation

• Vehicle Speed measured through using Pitot Tube or Paddle Wheel

• Moving Prop Alert warning light output

• Propeller Speed Sensor

• Reduced ECU Transmit Mode for Integration with vessels that have a 250kbps CAN bus speed

• Steering Pump Output

• Throttle Limit Decrease Rate table for when a throttle limit is requested for smooth throttle reduction

• Fuel Water Content Sensor (Water in Fuel Sensor)

• Water Inlet Temperature Sensor

• Like anything, the MoTeC M1 requires knowledge and experience to gain the best results. While we are happy to answer technical questions, purchase of this M1 firmware does not come with unlimited tuning support. We can quote tuning for your particular setup, refer you to someone in your area, or if you prefer to do it yourself (and lack the experience) then we can also quote training.

• This firmware is for closed course competition vehicles only. It does not meet federal emissions requirements.
